Features

  • Made in America design and quality
  • DC input power up to 30V
  • 350, 500 and 700mA constant current output
  • Customization of specifications available
  • Small 0.79”x 0.66”.0.43” mechanical envelope
  • Output open circuit and over temperature protection

Download

Applications

Literature

MiniPuck F004 – MiniPuck F004 Data sheet

  • Solar Lighting
  • Architectural Lighting
  • Point of Purchase Lighting
  • Automotive Lighting
  • Flash & Strobe Lighting

  • Track Lighting
  • Signal & Marker Lighting
  • Cabinet & Display Case
  • Sign & Channel Letters
  • Marine Lighting

Specifications

ProductF004-D-P-350F004-D-P-500F004-D-P-700
GeneralTopology:Buck
Input / Output:DC / DC
InputVoltage Range:6.5 to 30 V
Efficiency:97%
OutputDrive Current:350 mA500 mA700 mA
Current Accuracy:± 10% mA
Trim Range:None
ControlDimming:Yes
Type:PWM
ProtectionShort Circuit:Yes
Over Temp:Yes
EnvironmentOperating Temp:-40 to 80o C
Storage Temp:-40 to 125o C
Operating Case TempMax:-40 to 80o C
MechanicalConnection:5 Pin
Dimension:0.79 x 0.66 x 0.43 in
Weight:0.24 oz
RegulatotyCompliance:RoHS, UL
Warranty:2 Years

* All specifications are subject to change without prior notification.

Ordering Detail

Part Number Input VoltageDrive CurrentControlConnection
F004-D-P-3506.5 to 32 VDC350 mAPWM5 Pin
F004-D-P-500500 mA
F004-D-P-700700 mA
